Dual hydraulic cylinders, rotatable, multi-purpose excavator grapple

PTEROSAUR Hydraulic log grapple 360 degree rotary Grapples for excavatorPTEROSAU

+ ISO and CE certified manufacturer and supplier

+ One-Stop Service

+ Competitive Prices & High Quality Products

+ On Time Delivery

Get a quote Whatsapp

Overview

PTEROSAUR Hydraulic log grapple 360 degree rotary Grapples for excavator

PTEROSAUR hydraulic rotary grapple is widely used for handling, loading and unloading materials, sugarcane, wood, stone, steel slag,grabbing garbage, scrap metal and other special operations.

FEATURES AT A GLANCE

Log/Stone Grapple

1.Wide opening width with light weight, not only outstanding performance in handing the iron barbut also maximize the operation efficiency with light weight.

2.Unlimited clockwise and anti-clockwise 360 rotatable.

3.Special designed swing bearing for durability and big cylinder for more power.

4.Check valve is embedded for better safety shock value enclosed for better safety from damage.

5.Wear resistant special solid steel is used and no extra reinforcement is requirement.

6.Flexible choices dependent on job environment

7.Operator can control the rotating speed.

8.Versatile applications including handing of stones, wood, cane, pipes,disposable waste,landscaping works and many others.

PRODUCT SPECIFICATIONS

No	Item	Unit	BC 03	BC 04	BC 06	BC 08	BC 10	BC 14	BC 20
1	Weight	kg	320	390	740	1380	1700	1900	2100
2	Max jaw opening	mm	1300	1400	1800	2300	2500	2500	2700
3	Oil pressure	bar	110-140	120-160	150-170	160-180	160-180	180-200	180-200
4	Set up pressure	bar	170	180	190	200	210	250	250
5	Operating flux	L/min	30-55	50-100	90-110	100-140	130-170	200-250	250-320
6	Cylinder volume	Litre	4X2	4.5X2	8.0X2	9.7X2	12X2	12X2	14X2
7	Applicable excavator	Ton	4-6	7-11	12-16	17-23	24-30	31-40	41-50
